baofeng uv5r walkie-talkie outdoor radio high power dual band baofeng uv-5r walkie-talkie

Name: baofeng uv5r walkie-talkie outdoor radio high power dual band baofeng uv-5r walkie-talkie
SKU: 1000707070
Price: 29.99 USD
Availability: InStock

As low as $29.99

In stock

Only %1 left

SKU

1000707070

Skip to the end of the images gallery

baofeng uv5r walkie-talkie outdoor radio high power dual band baofeng uv-5r walkie-talkie

Skip to the beginning of the images gallery

Details

Overview

Essential details

Place of Origin:: Guangdong, China

Brand Name:: E-Style/OEM

Model Number:: UV-5R

Type:: Handheld

Dimensions:: 145*55*35mm

Frequency Range:: Unlimited

Storage Channel:: Unlimited

Talk Range:: Unlimited

Product Name:: Mobile Phone Walkie Talkie

VHF:: 136-174MHz

UHF:: 400-470MHz

Commercial FM Radio Receiver:: 65 MHz ~ 108 MHz

High power / low (5 W / 1 W):: Selectable

Channels:: Up to 128 channels

Alarm Function:: Yes

Dual Watch / Dual reception:: Yes

Battery Saving Function:: Yes

Battery:: 7.4V 1800mAh Li-Ion Rechargeable Battery

Certification:: ce, RoHS

Good Quality And Price Off Boafeng Up To 128 Channels Vhf Uhf Hf Bands Walki Talki,Built-In Led Flashlight,With Alarm Function

UV-5R is a micro-miniature multi band FM transceiver with extensive receive frequency coverage, providing local-area two-way amateur communications along with unmatched monitoring capability. With programming cable, support CHIRP.

Technical Specifications

General
Model NO.	UV-5R
Frequency Range	65 MHz ~ 108 MHz
Channel Capacity	128 channels
Channel Spacing	2.5/5/6.25/10/12.5/25 kHz
Output power	5W
Operated Voltage	7.4V
Battery	1800mah Li-ion Battery Pack
Battery Life	(5-5-90 duty cycle) About 8 hours
Frequency Stability	±2.5ppm
Operated Temperature	-30°c-+60°c
Antenna Impedance	50Ω
Dimensions (LWH) (with battery, without antenna)	14.55.53.5*CM
Weight (with battery/antenna)	0.520kg
Communication Range	3-5km
Transmitter
RF Power Output	5W
Modulation	F3E
Spurious Emission	≤65dB
FM Noise	≤-45dB(W) ≤-40dB (N)
Audio Distortion	≤5%
Transmitting Current	≤1.3A
Receiver
Sensitivity (12dB SINAD)	≤0.20 uV
Selectivity	55dB/50dB
Intermodulation	≥65dB
Adjacent Channel Selectivity	≥60dB
Spurious Response	≥60dB
FM Noise	45dB/40dB
Audio Power Output	1000mW
Audio Distortion	≤5%
Standby Current	≈15mA (with battery save on)
